102"x24' RawMaxx DTX Full Tilt
RAWMAXX FYH Low Pro Full Tilt Trailer
Model & Finish
22' long x 102" wide
Low-profile full power tilt
Color Chalk White
Frame & Structural Design
8" I-beam frame (13 lbs per foot)
3" channel crossmembers spaced 16" on center
6" outer deck frame
2" x 3/8" flat bar rub rail
3-7/8" x 1-13/16" inside dimension stake pockets
1-5/8" OD chain spool
3/16" thread plate drive-over fenders
Front rail guard
2" treated lumber deck
Axles, Suspension & Running Gear
Two 7,000 lb torsion axles
ST235/85R16 10-ply radial tires (4)
Tilt & Hydraulic System
Full power tilt deck
Dual 3" x 20" hydraulic cylinders
13° tilt angle
KTI hydraulic pump with wireless remote
10W solar panel
Hitch, Jack & Safety
2-5/16" adjustable ball coupler
10,000 lb side-wind drop leg jack
Integrated tongue toolbox
3/8" G70 safety chains
3M DOT-compliant reflective tape
Cargo & Utility Features
Four weld-on D-rings
Integrated winch plate
Electrical & Finish
All-weather wiring harness
Powder coat paint finish
Warranty
5-year Dexter axle warranty
3-year structural warranty
1-year paint warranty
